Perlmutter Supports First Gravitational Lensing System Modeled on GPUs

Science Highlight

September 20, 2023

On the left, a white square delineates a set of illuminated objects in space: four white lights in a cross shape surrounding a central yellow light. On the right, a magnified inset image of the same image.

Light bent by the gravity of a massive object can project four images of a distant galaxy in a cross-shaped configuration. (Credit: Aleksandar Cikota, et al, and  ESO/VLT/MUSE)

Science Breakthrough

Using the GIGA-Lens modeling code on the Perlmutter supercomputer at NERSC, a team of researchers has modeled a rare instance of strong gravitational lensing known as an Einstein Cross – likely the first such system to be modeled on graphical processing units (GPUs) and a demonstration of the promise of GPU-accelerated modeling. Their research was published in The Astrophysical Journal Letters.

Science Background

Gravitational lensing occurs when the gravity of a massive object warps space-time in such a way that the path of light from a more distant source bends, sometimes producing multiple images of the source. It’s a powerful tool for astronomers and cosmologists studying dark matter since it can help researchers understand the location and distribution of dark matter not easily detected in other ways. When the mass acting as a lens is elliptically distributed, and the alignment of the light source is just right, a cross pattern of four images with the identical color of the source appears: the Einstein Cross.

Science Breakdown

Researchers identified this gravitational lensing system, DESI-253.2534+26.884, in the data from Dark Energy Spectroscopic Instrument (DESI) Legacy Imaging Survey using deep neural networks, then modeled it on Perlmutter using GIGA-Lens, a Bayesian lens modeling pipeline. The system is believed to be the first real gravitational lensing system modeled with GPUs; on a single A100 GPU, the model was completed in 55 seconds, a drastic reduction from the average of 4.3 hours reported in a previous study. Modeling the system on a single node of four GPUs, the paper’s authors believe the modeling time could be reduced even further to 15 seconds.

Research Lead

Aleksandar Cikota, NOIRLab


I. Toro Bertolla, X. Huang, S. Baltasar, N, Ratier-Werbin, W. Sheu, C. Storfer, N. Suzuki, D.J. Schlegel, R. Cartier, S. Torres, S. Cikota, E. Jullo


Cikota, A., et al. “DESI-253.2534+26.8843: A New Einstein Cross Spectroscopically Confirmed with VLT/MUSE and Modeled with GIGA-Lens”

Aleksandar Cikota et al 2023 ApJL 953 L5

DOI 10.3847/2041-8213/ace9da


The U.S. Department of Energy, Office of Science, Office of High Energy Physics partially funded this work.
