The Atomic Dynamics of Rare Magneto-Electric Matter

Molecular Dynamics Computations Run at NERSC Help Confirm Theoretical Model

February 14, 2018

Contact: Kathy Kincade,, +1 510 495 2124

By ricocheting neutrons off the atoms of yttrium manganite (YMnO3) heated to 3,000 degrees Fahrenheit, researchers have discovered the atomic mechanisms that give the unusual material its rare electromagnetic properties. The discovery could help scientists develop new materials with similar properties for novel computing devices and micro-actuators.

The experiment was conducted as a collaboration between Duke University and Oak Ridge National Laboratory (ORNL) and appeared online in Nature Communications on Jan. 2, 2018. Their work included large-scale quantum simulations of atomic behavior run on supercomputers at the National Energy Scientific Research Center (NERSC) at Lawrence Berkeley National Laboratory. NERSC is a Department of Energy Office of Science User Facility.

multiferroic yttrium maganite

Intensity maps showing behavior of collective atomic oscillations in multiferroic yttrium maganite (YMnO3), comparing neutron scattering experimental data (left) and quantum molecular dynamics simulations (right).


Ferromagnetism is the scientific term for the phenomenon responsible for permanent magnets like iron. Such materials exist because their molecular structure consists of tiny magnetic patches that all point in the same direction. Each patch, or domain, is said to have a magnetic dipole moment, with a north and a south pole, which, added together, produce the magnetic fields so often seen at work on refrigerator doors.

Ferroelectricity is a similar property, but more rare and difficult to conceptualize. In much the same way as a permanent magnet, a ferroelectric material consists of domains with electric dipole moments aligned with one another. This produces a naturally occurring permanent electric field, like a collection of microscopic balloons with a long-lasting charge of static electricity.

Yttrium manganite is one of the very few materials that combine both the ferroelectric property and also magnetic ordering at extremely cold temperatures. This rare combination presents the interesting possibility of controlling the material’s magnetic properties with electricity and vice versa. Harnessing this ability could let scientists create more efficient computers based on four digit-states rather than just today’s 1s and 0s by flipping both electrical and magnetic states, as well as new types of sensors and energy converters.

“These so-called multi-ferroic materials are very rare,” said Olivier Delaire, senior author on the paper and associate professor in the Department of Mechanical Engineering and Materials Science and the Department of Physics at Duke. “But if we can understand the mechanisms of what is happening at the atomic level, we have a better chance of designing and discovering more materials enabling new technologies.”

Probing Atomic Vibrations

Because the ferroelectric behavior of yttrium manganite turns on at very high temperature (above 1800F) researchers had never been able to probe the atomic vibration waves that yield the desired arrangement of microscopic electric dipoles. So, while the molecular underpinnings of yttrium manganite’s ferroelectric properties have been theorized before, there had never been direct measurements to prove them.

To determine how the property arises, researchers must probe the wave-like vibrations of the stacking of atoms in the material, which oscillate at frequencies over a thousand billion times per second, and they must to that both above and below the 1,800F ferroelectric switching temperature, which is a tall task, to say the least. But that’s precisely what the researchers did.

The experiments involved shooting the extremely hot sample of yttrium manganite with neutrons. By detecting where the neutrons ended up after colliding with the sample’s atoms, the researchers could determine where the atoms were and how they were collectively oscillating. There are very few places in the world that have such capabilities, and the Oak Ridge National Lab, a few hours drive from Duke, happens to host both the High-Flux Isotope Reactor and the Spallation Neutron Source, the most powerful source of neutron beams in the world.

The researchers probed the material using neutrons at various energies and wavelengths, giving an overall picture of its atomic behaviors. They found that above the transition temperature, a certain group of atoms were free to move around and vibrated together in a particular way. But as the material cooled and shifted phases, those atoms froze into the permanent crystalline arrangement that is responsible for the ferroelectric properties.

To validate their experimental findings, the researchers performed simulations of atomic vibrations (phonons) on NERSC’s Cori system using both first-principles methods (especially density functional theory) and molecular dynamics. The simulations also were benchmarked and validated against phonon measurements performed by the Delaire group the at the Advanced Photon Source at Argonne National Lab.

“Our quantum dynamics simulations of harmonic and anharmonic atomic oscillations in YMnO3 provided both initial guidance for–and rationalization of–our neutron scattering measurements,” said Dipanshu Bansal, a postdoctoral scholar in the Delaire research group at Duke and lead author on the Nature Communications study. “The detailed study combining ab initio molecular dynamics (AIMD) simulations and neutron scattering measurements confirms the theoretical predictions and enabled further insights into the peculiar atomic dynamics in these technologically important materials. The proper treatment of such anharmonic terms in YMnO3 required computationally intensive AIMD simulations on a large crystal unit cell, which became feasible with the supercomputing power of Cori at NERSC."

This material was never previously understood on such a fine atomistic level, added Bansal and Delaire. “We’ve had theories about the importance of atomic oscillations, but this is the first time we’ve directly confirmed them. Our experimental results will allow researchers to refine theories and create better models of these materials so that we can design even better ones in the future.”

This article was adapted from a Duke University press release.
